CHMT560P4 Desktop SMT pick and place machine, 4 Heads 30 feeders, Yamaha feeder 8, 12, 16, 24mm

SKU. 117323

$ 7,900

Stock:: 50 in Stock

Quantity:: - +
piece(s)

Shipping:: Free Shipping

Can't deliver

To Be Negotiated

to United States Change

Estimated delivery time : 3-15 working days.

Total Price:: $ 7,900 $ 0.00 save $ 0.00

Shipping calculated at checkout.

Buy Now

Add to Cart

Shipping & Returns
Get a Quote

CHMT560P4

PDF
CHM-T560P4 User Manual- Charmhigh.pdf

Description
Specification
Q & A
Customer Reviews
Shipping Policy
Wholesale Inquiry

CHM-T560P4 Introduction

Desktop SMT pick and place machine Charmhigh CHM-T560P4, 220v/110v

4 heads 60 feeders, for PCB assembly line, good for small batch production

0603 by pneumatic feeder, 0402 by electric feeder - CHMT560P4 mounting video:

https://youtu.be/waJ9K3ok7r4

CHM-T560P4 main features

1. Model number: CHM-T560P4

2. Brand: Charmhigh

3. Main configuration: Desktop type + 4 Heads 60 feeders + built-in PC + Embedded Linux system + closed-loop control motor with encoder + 2 cameras + linear rail + auto calibrate PCB + touch screen
4. Feeder: 2 options: Yamaha pneumatic feeder & Electric feeder (feeders purchase separately)

5. PCB area: 400*270mm

6. Component: 0402-5050, LED, SOT, SOP, QFN... etc.

7. Dimension: 1180mm(L)*870mm(W)*600mm(H)mm; AC220V/110V (50/60Hz)
8. Lead time: 2-3 working days
9. Delivery: by DHL express door to door / by air / by sea / pick up from our factory directly / send to China warehouse
10. Payment method: Credit card, Wire transfer (T/T); PayPal; W/U

11. Packing: plywood box

CHM-T560P4 description

This CHMT560P4 is an updated desktop pick and place machine which works with Yamaha feeders.

It has 4 heads with 60pcs feeder slots, front side 30pcs plus back side 30pcs, for small smt production is your good helper!

The operating system is an industry-level embedded Linux system, the main board of the machine was researched by ourselves, which is more reliable than the windows system, and its lifetime is much longer.

CHMT560P4 uses 502---507 different kinds of Juki nozzles, suitable for 0402,0603,0805-5050, LED, SOT, SOP, QFN, BGA, Diode, Transistor...etc, which can meet more customers' demand. Very good for small batch production or prototyping or education.

It has double vision cameras, which can auto-calibrate the PCB before running, and auto-correct pick position and angle.

Dimensions

1180mm(L) x 870mm(W) x 640mm(H)

Net Weight

140kg

Power Supply

AC220V (50Hz, single phase) /AC110V (60Hz, single phase); 400W

Air Supply

0.5MPa ~0.7MPa

Vacuum Generation

Built-in vacuum pump

Mounting Head

4 heads

Mounting Speed

8000cph(optimal without vision detection);
5500cph (optimal with vision detection)

Control Accuracy

0.015mm

Component Type

0402/0603 ~ 5050/SOT/SOP/QFP/QFN/BGA, etc.
(resistor/capacitor/diode/triode/LED/IC, etc.)

PCB Thickness

0.6mm~3.5mm

PCB Size

10mm(L)x10mm(W )~ 400mm(L)x290mm(W)

PCB Conveying

Manual operation

Nozzle Change

Manual operation

Control System

Built-in computer (embedded Linux operating system),
7-inch touch screen

Drive System

X&Y-axis driven by stepping motors in the way of closed-loop control;

Z-axis capable of reset detection;

all motors adopting flexible S-curve acceleration and deceleration

Transmission System

Synchronous belt + linear guide

Feeding System

60 Yamaha 8mm standard pneumatic feeder stacks (also suitable for

Yamaha electric feeder, IC tray, and stick feeder), 11 preset general IC stacks,

work surface custom IC trays supported

Vision System

Up-looking camera for component automatic calibration

(component size applicable: 22mmx22mm); down-looking camera for PCB
calibration via Mark Point and component positioning

Work with Yamaha pneumatic feeder and electric feeder:

option: 8mm/12mm/16mm/24mm and vibration feeder

Standard Accessories for CHMT560P4:

1) Pick and Place Machine CHMT560P4: 1

2) Juki nozzle total 4pcs (503, 504, 505, 506 size)

3) 8G USB driver 1

4) Power Cord 1

5) Grease 1

6) Hex wrench 6

7) Tweezers 1

8) Brush 1

9) Additional belt set 1

10) Pen for touch screen 1

11) Fixture for IC tray 4

Please note:

The pick and place machine is a complete set with all accessories included in the package, machine is ready to use!

The only thing you need to prepare is an external air compressor with 8mm outer diameter pipe (supplying air for pneumatic feeders), inserting the pipe on the rear of the machine.

Please purchase this machine with confidence.

Enjoy with your pick-and-place machine!

Service& Warranty:

The complete machine has a warranty period of 1 year from the time of purchase and lifetime service.

We always provide spare parts of machines, factory direct supply with a guarantee.

We provide online Q/A and troubleshooting support and technical advice service.

We provide one-to-one after-sale service. Each machine 100% tested well before shipping out.

Tech support:

Kimi'sMob/ WhatsApp: 0086 135 106 75756

Skype:kimiliu89

E-mail: kimi@charmhigh-tech.com

Welcome to follow us on YouTube: www.youtube.com/kimiLiuCharmhigh

If you want to know more information, please contact us by E-mail.

We will reply you as soon as possible.

Why choose Charmhigh?

1. Professional design and room saved.

2. User-friendly operation, no need professional SMT engineer, entry-level device

3. One machine - Integrated operation, no need extra pump or PC or any supporting facility.

4. Cost efficient, reduced expense to own a professional full automatic SMT production line.

5. It is very convenient to change machine replacement, easy to fix by yourself.

6. International express with door-to-door service, 6-8 working days delivery.

7. Especially for laboratory research and development, to protect your own design and patent.

8. One machine equals to 5 soldering staff, much higher efficient than manual work, easy to manage and cost-saved. Good for small batch production.

9. Charmhigh is factory supply, all of our machine parts are researched and manufactured by ourselves. After-service spare parts never stop.
10. Charmhigh is a professional manufacturer of SMT Pick and Place machines since, first p&preleased in 2011. All the software was researched by ourselves, and we provided good after-sell service.
